The automatic rubber molding press is utilized for vulcanizing all sorts of rubber and plastic products.
Features
- The vulcanizing press features a column structure, including the main machine, hydraulic station, and electric control cabinet. The main machine is comprised of a base, plunger piston, platform, beam, automatic mold pushing-out device and compulsory mold opening device.
- Under PLC control, this machine achieves automatic mold closing, vulcanization timing, exhausting time and frequency setting, mold opening, mold pushing, and so on.
Technical Parameters
| Type | |
| Total pressure(mn) | 1.60MN |
| Plate size(mm) | 600X600 |
| Plate daylight (mm) | 350 |
| Daylight no | 1 |
| Piston stroke(mm) | 350 |
| Plate unit area pressure(kg/cm2) | 44.5 |
| Overall dimension(mm) | 700X1700X1800 |
| Weight(kg) | 5100 |
