The bearing type rubber mixing mill is utilized by rubber processors for plasticizing and mixing rubber and plastic materials.
Technical Parameters
| Mode | ||||
| Roller diameter (mm) | Φ550 | Φ660 | ||
| Working length of the roller(mm) | 1500 | 2130 | ||
| Working linear speed of front roll (m/min) | 27.94 | 28.1 | ||
| Friction ratio of front and rear roll (m/min) | 1 ∶ 1.22 | 1 ∶ 1.24 | ||
| Max gap(mm) | 15 | 15 | ||
| Capacity per batch (kg) | 50-60 | 165 | ||
| Driving motor power ( Kw ) | 110 | 245 | ||
| Overall dimension (mm) | L | 5900 | 7465 | |
| W | 2680 | 3662 | ||
| H | 2080 | 2750 | ||
| Weight (kg) | 27000 | 6500 | ||
| Note | Bearing | |||
