Technical Parameters
- Cutting efficiency: >120times/min
- Rotational speed of operation: 0~2500r/min
- Cutting precision: ≤±0.03mm
- Cutting diameter: Φ10mm~Φ260mm
- Cutting length: standard type≤140mm. Extended Edition≤400mm
- Cutting wall thickness: ≤20mm
- Consumption amount of compressed air: 20L/min
- Air pressure: 0.5mpa~0.8mpa
- Working vacuum degree: ≤-0.035mpa
- Power supply: AC220V ± 5%
- Total power: 2kw
- Equipment weight: 580kg
- Equipment dimensions (L*W*H): 1750mm*750mm*1600mm
Other Term
- Total price: USD9800
- Delivery time: 45days
- Payment term: FOB
- Payment :The deposit is 30%T/T of whole price as downpayment，Then the balance 70% of whole price should be paid before delivery by T/T
- Packing wooden case
- Port of shipment: Qingdao
- The quotation is valid for one months after the issued date of this quotation
Quality Guarantee
- The quality guarantee period is one year after delivery.
- Under guarantee period, our company will change or repair the damaged equipment for free if they have deficiency of design or manufacture.
